SOLD on 4th July2008.
20mths 2week old.

Final Grace of the Car

My HKS Honda Civic FD1.
A great ride! Retired in june 2008 to make way for new ride .

I will be missing it.....

Specification
JDM R18 Civic FD1A
Engine
HKS Fcon IS
HKS AF IF Unit
HKS Induced Suction Intake
HKS Sparkplugs
Carbing Oil Catch Tank
HKS D1 Limited Edition Radiator Cap
HKS Limited Edition Billet Oil Filler Cap
Fujisubo Legalis R Exhaust
R18 Engine Cover
Tial Waste Gate
Greddy TYPE RS BOV
Front Mount Intercooler
TD04H Turbo

Suspension & Wheels
JBT Front 4pot brake kit
Limited Edition 17" SSR Spec C Euro 114.3*5 8jj. Competition Silver
Cooper Zeon 2XS 215/45/17
Alutec Front Strut
Ultra Racing 16mm Rear Antiroll Bar
UR 4 Point Under Brace
UR 4 Point Rear Tie
BC Coilovers
Skunk2 Rear Camber Kit
SPC front camber nut

Interior
Recaro NRS Reclinable Seats
HKS Type-1 Turbo Timer
HKS Fcon IS Full Parameters 5" Monitor
HKS Fcon IS sensors:
Oil Temp, Oil Pressure
Water Temp, A/F
Boost, Pressure, etc...
HKS Boost gauge
HKS EVC V Boost Controller
Red Key Illum
Garmin Nuvo
Mugen Handbrake Cover Replica

Exterior
Mugen Front Bumper
Mugen Rear Bumper
Mugen Side Skirt
Mugen Grill
CF bonnet

0-100km/hr: 6.9sec
225hp 250nm 0.55bar
175hp 225nm 0.38bar

Final Sepang Ride

Vented CF Bonnet for Civic FD

Vented CF bonnet was added for better engine bay cooling.

This is a Custom made real carbon fibre CTR bonnet made in Japan.

Spraying of intercooler ?

Intercooler sprayed black to avoid problems.
Safe driving promoted. =)

The cockpit

A look into the legendary turbo charged Civic FD1a

How do my engine bay looks? The first tced fd1a by garage R.

HKS-Zage Turbo Kit by Garage R

After 6mths of ordering and indent since early 2007.
For more sporty and power performance.
A HKS-Zage Turbo Kit by Garage R was added.
Very nicely done! Thumbs up!
Not suitable for the irresponsibles...

Pasir Gudang 2007

Overall handling is great!
Loving it!

Additional of Skunk2 Camberkit

Skunk2 Camber Arms Added to improve handling.
SPC front camber nuts added.
Front -2.5, Rear -1.5

Sepang 2007

SSR Spec C

New 17" rim added. The 18" is just too heavy.
The SSR Spec C is light and semi forged.
Limted Ed SSR Spec C Euro. Competition Silver.
215/45/17. 17x8jj for more tyre option. offset 38
Notice the flower locklut for antitheft.

HKS Fcon IS with Display by Garage R

The HKS New Fcon IS added to my honda civic fd1a to manage
the car, also added the HKS open pod induced suction intake.
The HKS Fcon IS + HKS AF IF unit with full sensors that
is able to display every parameter on a display unit.
.

Recaro NRS Reclinable Seats

The Recaro NRS Reclinable Seats
Comfortable seats that provided the sport grip, fierce look and
yet comfortable lumbar support.
No regrets! $2K + for the pair!

BC Coilovers

Installed the BC coilovers. No regrets.
Surprisingly the BC coilovers by Taiwan
is superbly made and its damping adjustable.
VERY STIFF , VERY GOOD TO HANDLE!
Forget about Tein. Here is the value for money
coilovers made by the Chinese.

Tried 10 front 10 back setting,
feels alright if you don't like it hard.

In the end my friend set 0 front 0 back.
Used this setting to track and daily drive.
Nice is word i like to describe!

AFC Neo

AFC NEO on civic fd.
Installed and removed in a month.
Better butt feel but not enough..
Nice interface with intregrated shift lamp.

Buying a 2nd hand exos?

Buying a 2nd hand exhaust in singapore?
It requires the LTA approval,
How to go about doing it?

1. Install your newly purchased exhaust system at any garage.
Fee cost ard $30 to $70 depending on which garage you go.
2. Have your Jasma or exhaust certificate done for transfer of ownership
at the main importer. Transfer fee varies. For fujisutbo is $50.
3. Go the your nearest Land Transport Authority to have it checked
for emission and noise etc. Pay a $52.50 for inspection.
4. Passed! You go home a happy man.
4a failed!!! damn... dismantle it or face a fine!

You have 1 month to go to inspection after installation.
If within 1 month you never go, and you got caught by LTA.
Good luck to you.

Handlings & Exos

Ultra Racing antiroll bar, 4point underbrace and 4point rear tie are
used to improve handling.
Alutec front struct bar is used for its light weight.


Fujisutbo Exhaust is the best choice for future modifications
for the FDs. Sound goods and better potential for more power!

JBT brake kit

A better brakes system is now required for my civic!
ARD $1780 for the JBT mini 4 brake kit.
Selected the JBT mini 4pot kit as it produce great modulation, light in weight.
Believed that big doesnt mean good. Steel brake hose helps.
BTW: the stock civic fd brakes sucks.
With 330mm slotted brakes disc. Power braking and fierce look!
